      Diamond DA 42 Twinstar
      performance and specifications

                              DA 42
                              Twinstar

                              The Diamond DA-42 Twin Star is
                              an all new four place carbon fibre construction
                              light twin powered by jet fuel burning turbo
                              diesel engines.

                              Austria's Diamond Aircraft unveiled the DA-42 at
                              the May 2002 Berlin Airshow. The new aircraft flew
                              on December 9 2002, leading to European JAA
                              certification in late 2003 and US FAA
                              certification and first deliveries in mid 2004.

                              The Twin Star's design objectives include high
                              speed cruise at very low throttle settings and
                              good low speed handling. It is loosely modelled on
                              Diamond's DA-40 Diamond Star single engine four
                              place (see separate entry), and features an all
                              composite airframe with a high aspect ratio wing
                              with winglets.

                              The heart of the Twin Star is its two Thielert
                              Centurion 1.7 (formerly TAE-125) turbo diesel four
                              cylinder engines, which are designed to run on
                              either diesel or Jet-A1/jet fuel. Germany based
                              Thielert's Centurion turbo diesel engine was
                              certificated in early 2002 and is based on a
                              Mercedes-Benz automotive design. Diamond expects
                              the DA-42's two engines will burn just 45 litres
                              an hour while cruising at a very fast 333km/h
                              (180kt). Standard fuel capacity is 200 litres,
                              while optional long range tanks take maximum fuel
                              capacity to 280 litres.

                              The engines drive slow turning three blade
                              constant speed propellers, which combined with the
                              engines' low noise emissions and the DA-42's fast
                              climb rate will result in a low ground noise
                              signature. The engines also feature electronic
                              fuel management, automatic prop controls and auto
                              feather.

                              The Twin Star will feature dual controls and an
                              optional EFIS glass cockpit with three vertical
                              format colour LCDs. The basic aircraft will be
                              equipped with conventional IFR avionics.


                              Diamond Aircraft says the DA-42
                              will be suitable for flight training as well as
                              private and business use.

                              Embry-Riddle Aeronautical University was the
                              launch customer with an order for 10, and
                              Lufthansa ordered 40 for its pilot training
                              school. Another customer is PureFlight of the UK
                              which ordered the Twin Star for its fractional
                              ownership programme




                              engines
                              Two 100kW (135hp) Thielert Centurion 1.7 avtur
                              burning turbo diesel four cylinder piston engines
                              driving three blade MTV-6A-129 hydraulic constant
                              speed propellers.

                              performance
                              Cruising speed at 95% power at 12,000ft 376km/h
                              (203kt)
                              economical cruising speed 334km/h (180kt)
                              Initial rate of climb 1700ft/min
                              Max operating altitude 20,000ft
                              Range at 60% power with standard fuel 1912km
                              (1061nm), with optional fuel tanks 2677km (1485nm)

                              weights
                              Empty 1030kg (2270lb)
                              max takeoff 1650kg (3673lb)
                              Payload 620kg (1366lb)

                              dimensions
                              Wing span 13,42m (44ft)
                              length 8.5m (27.8ft)
                              height 2.6m (8,5ft)
                              Wing area 16.5 m2 (177.2sq ft)

       |
