            Rans S-7S
            Courier







            The S-7S Courier has evolved from
            the classic S-7 Courier produced since 1985. The constant progress
            of the Courier kit has produced the S-7S. Along with the tremendous
            value added from building a certified aircraft in kit form, come
            refinements in aerodynamics, interior, panel, fibreglass wing tips,
            larger flaps, radiator inside cowling, and a fibreglass cowl boot.
            Options such as cabin heater, welded jury struts, wing fabric rivet
            kit, airspeed indicator, voltage meter, fuel pressure gauge, station
            3 close out, control stick cover-ups, throttle guard, and bubble
            doors now come standard on the S-7S.

            The S-7S
            Courier is a classic in the true sense of the word. From the
            tasteful lines to the touch, smell and feel, it beckons of an era
            when flying was a grass roots experience. When flying was a personal
            enjoyment without the pressure to make it pay or need to be
            justified in the eyes of ”accounting.” The S-7S is flying for the
            sake of flying. It is quality airtime. Time well spent getting in
            touch once again with why you earned your ticket.

            Flying the Courier develops a profound respect for the evolution of
            a classic. No doubt about it, the Courier has been influenced by
            great planes – like the Cubs and Champs – except evolved to an
            advantage. At first introduction you will welcome some more obvious
            changes. Two five-foot wide doors allow easy entry to either the
            solo position front seat or rear.

            Equipped with the Rotax 100 HP 912S engine, the Courier can leap
            into the air in less than 325 feet. Lifting off short means little
            if you can’t haul a load. 532 pounds of useful load puts the Courier
            in the ”do something, go somewhere” class. Tough spring steel gear
            and effective Cleveland  brakes let you do
            that something in places previously passed by. The gentle nature of
            this taildragger will encourage the newcomer and compliment the
            seasoned. Developed in the land of daily crosswinds (Kansas), the
            Courier is good for 20 KTS. at 90 degrees –
            more if you know a few tricks!

            In the air, the Courier parts company with some of the classic
            element, leaving behind the pronounced adverse yaw and rudder
            tending. Instead, the handling reveals the fine tuning of
            differential ailerons, spades, balanced controls, and smooth ball
            bearing bellcranks and push rods.

            A gentle buffet announces the stall followed by a definitive break.
            A slight release of back pressure and the Courier is flying again.
            Even at the bottom of the white arc, the Courier retains confident,
            friendly handling. This is the outcome of just the right airfoil,
            span and wing loading. Enjoyable handling that lets you fly to the
            extremes of your personal envelope.

            A healthy supply of fuel (18 gallons) yields at least 3.1 hours
            aloft with 1/2 hour in reserve. Another pleasant surprise is the
            cruise speed. Here’s where that narrow Rotax 912S really pays off.
            Cruise at 118 MPH, now that really puts some ”refinement” into the
            old cub numbers!

            Get used to seeing. The view out of the Courier is amazingly void of
            blind spots. Another break from tradition is over- the-nose
            visibility during taxi, which turns exceptional in the air. Five
            foot long side windows pan the horizon. For over-the-wing
            visibility, the cabin roof is clear glazing. That comes in real
            handy in the pattern or winding along a riverbed.

            Fun to toss around the sky, but yet stable. Tap the Courier’s
            electric trim on top of the control stick to set up hands off
            cruise. Drop the flaps and re-trim. The big tail and long moment
            provide good feel with proper feed back.





               specifications



                powerplant
                propeller
                length
                height
                wing span
                wing area
                seats
                empty weight


                useful load
                gross weight
                fuel capacity
                range |

                Rotax 912S
                100 hp

                72 in
                Carbon

                23 ft. 3in.

                6 ft 3 in

                29 ft 3 in

                147.1 sq ft

                2

                700 lbs

                500 lbs

                1200 lbs


                18 gal US

                341 miles |



            performance





                takeoff
                distance, ground roll
                rate of climb
                max speed
                cruise speed
                landing distance, ground roll


                service ceiling |

                325 ft

                1000 fpm
                x

                110 mph

                375 ft

                14,500 ft |



            limiting and recommended speeds




                design
                manoeuvring speed (Va)
                never exceed speed (Vne)
                stall, power off (Vsl)
                landing approach speed  |


                x

                130 mph

                46 mph
                x |


            All specifications are based on
            manufacturer's calculations
   |





           |



    |
