              FOKKER D-VI
              Biplane3/4
              scale replica
      Airdrome
      Aeroplanes








            All aluminium tubing to complete
            fuselage, wings, landing gear, cabines, lift struts, and formers.
            All aluminium sheet metal to construct gussets, cowling, & seat. All
            machined parts for control systems, lift struts, axles, and wings.
            All AN hardware to build aircraft, eye bolts, locknuts, thimbles,
            nico press swedges , aircraft cable (rudder cables, drag/anti/drag
            braces). Ball bearing rod ends for control system. Stainless steel
            pop rivets. Main wheels, tail wheel, spun aluminium nose bowl, plans
            and builders video.






               specifications



                powerplant
                propeller
                length
                height
                wing span
                wing area
                seats
                empty weight

                useful load
                gross weight
                fuel capacity
                range |

                Rotax 503, 52 HP  VW
                Torquemaster
                x

                x

                x

                x

                x
                1
                297 lbs

                242 lbs

                x

                x

                x |



            performance





                takeoff distance,
                ground roll
                rate of climb
                max speed
                cruise speed
                landing distance, ground roll


                service ceiling |

                x
                750 fpm
                78 mph
                70 mph
                x
                x |



            limiting and recommended speeds




                design manoeuvring speed (Va)
                never exceed speed (Vne)
                stall, power off (Vsl)
                landing approach speed  |


                x
                x

                32 mph
                x |


            All specifications are based on manufacturer's
            calculations
   |





             |



    |
