Jabiru SP-T

The Jabiru SP-T is the new taildragger version of the Jabiru SP model. The SP has the longer (600mm/2’) fuselage extension and the standard 8 metre (26’4") wingspan. The SP-T taildragger has the main gear moved forward, a larger rudder, differential braking through toe brakes and a steerable tailwheel.

The SP-T model also incorporates the standard Jabiru 6 cylinder cowlings which can accommodate the builder’s choice of Jabiru’s 4 cylinder 8Ohp engine or its 6 cylinder l2Ohp engine. Cruise speed with the 4 cylinder engine is 105 knots and 120 knots with the 6 cylinder engine.

specifications

powerplant
propeller
length
height
wing span
wing area
seats
empty weight
 useful load
gross weight
fuel capacity
range		 Jabiru 2200cc - 80hp or 120hp
 2 Blade Fixed Pitch Wooden/Composite 60" dia
 18’ 5"
 6’ 6"
 26'3"(SP) & 30’ 8"(UL)
 85 sq ft (SP) & 100 sq.ft UL
2
 (532.4 lbs) (578.6 lbs)
 (457 lbs)
 (1034 lbs) (1100)
 14.3gals
 430nm

performance

takeoff distance, ground roll
rate of climb
max speed
cruise speed
landing distance, ground roll
 service ceiling		 325ft
 x
 100kts(4Cyl) & 120kts(6Cyl)  110kts(4Cyl) & 132(6Cyl)
 90kts
 546ft
 15,000ft

limiting and recommended speeds

design manoeuvring speed (Va)
never exceed speed (Vne)
stall, power off (Vsl)
landing approach speed 		x
 120kts (4Cyl) & 132kts
 35kts
x

All specifications are based on manufacturer's calculations
