              The distinctive Knight Twister
              is the oldest aircraft design offered by Steen Aero Lab and has
              quite an interesting history dating back to the late 1920s.
              Launched in 1928 by Vernon Payne as a way to liven up an aircraft
              design class he was teaching, the design draws heavily upon NACA
              aerodynamic research.
            The Knight Twister in any version is a true
            thoroughbred. While it is not like the average trainer in control
            response, the fact is that the design simply doesn't need to be
            horsed around the sky. It is the kind of plane that thrives on
            smooth control inputs, and in return she will reward the pilot with
            smooth, perfectly-balanced performance. Properly-built Twisters tend
            to be very straightforward and easy to fly airplane with excellent
            performance, which give great enjoyment to their pilots.
            Construction methods are conventional. The
            fully-cantilever wing and tail surface construction is mostly of
            plywood (it's too small to use a built-up truss structure
            efficiently) while the fuselage is built of welded steel tubing. The
            wings are fully cantilever and stressed to 7-9 Gs (depending upon
            the version) though the addition of flying wires raises the strength
            somewhat. Since the first flight with a 45 horsepower radial engine
            in 1929, the Twister has gone through at least eleven different
            versions and probably around 75 have been completed. The popular
            KT85 version appeared after World War Two and this lead to the
            versions available today: the "Imperial", "Holiday", "Acro" and the
            two-place "Coed". Power options range from 85 hp to 150 hp.




            Coed





               specifications



                powerplant
                propeller
                length
                height
                wing span
                wing area
                seats
                empty weight

                useful load
                gross weight
                fuel capacity
                range |

                Lycoming HP Range 108/85-160
                x



                13.5ft



                5ft



                15.5ft



                55sq. ft
                1/2



                517lb



                x



                865lb





                20gal



            610n.m |



            performance





                takeoff distance,
                ground roll
                rate of climb
                max speed
                cruise speed
                landing distance, ground roll


                service ceiling |



            400ft



            1800fpm



            180mph



            165mph



            800ft
                x |



            limiting and recommended speeds




                design manoeuvring speed (Va)
                never exceed speed (Vne)
                stall, power off (Vsl)
                landing approach speed  |


                x
                x



            55mph
                x |


            All specifications are based on manufacturer's
            calculations
   |
