Engine                          The engine is a Bombardier-Rotax, Type 912 S, 4 cylinder, 4 stroke featuring opposed cylinders, dual electronic ignition, dry sump with oil pump, liquid cooled heads, and an integrated gearbox with torsional dampener. It is equipped with a 12V/250 Watt generator, two Bing 32 mm carburetors, a 0,6 KW electric starter and a mechanical fuel pump. The Rotax 912 S develops 98 HP at 5800 RPM at take-off and 92 HP at 5500 RPM for continuous operation.

Propeller                     Three-bladed, 68 inches,  ground adjustable

Fuselage                       Vacuum molded composite structure consisting of a S-glass- vinylester resin laminate with rigid PVC foam core.

Wings and tail              The all-metal wing is a single-strut, single spar construction, covered with aluminum skins. The horizontal empennage features a cantilever stabilizer structure covered with aluminum with fiberglass tips. The rudder, ailerons, flaps and elevator are skinned with aluminum.

Controls                      The airplane features a dual control stick system, dual rudder pedal system and differential braking system.  Ailerons are deflected through a bellcrank/push-rod mechanism mounted on ball bearings.  Flaps are operated by a torque tube connected to a mechanical lever in the console. Ailerons deflect 10° with full flaps (45°) . Rudder and elevators are cable operated.  The elevator trim tab is mechanically operated and combined as an anti-servo tab .  Fixed trims are used for the rudder and the ailerons.

Landing gear                 The main landing gear legs are made of heat-treated 4130 spring steel tubing.  The system consists of a right and a left leg, connected by a center tube.  The legs are supported by aluminum blocks bolted inside an aluminum box. The nosegear leg is made of 4130 tubing with an aluminum fork.  Suspension is provided by a bungee chord. The nosewheel is steerable via push-rods connected to the pedals and it locks in flight.

Wheels & Brakes          The main wheels are 5 inch Cleveland with disk brakes and 500*5  tires. The nose wheel is a 6 inch Azusa with a 13 x 600 tire.

Fuel system                  Fuel is stored in two 12.0 USG composite tanks located in the wings and fed to the engine via a 0.2 USG aluminum header tank located behind the seat back. All three tanks are inter-vented and each wing tank is vented to the outside.

Flaps                            Mechanically operated by a Johnson bar - type lever located in the console.  They offer 5 positions from 0° to 45°.

Trim                            One elevator trim mechanically operated by a lever on the console.

Cockpit                         Two seats, side by side, foam seat cushions, dual sticks, dual pedals, center console, Lexan windshield and baggage compartment windows. The baggage compartment behind the seats has a  capacity of 50 lbs.

Seat belts                    Three-point seat belt - shoulder harness system for both seats.

Engine:                        Rotax 912 S-UL

Propeller:                     Three-bladed, Warp Drive ground adjustable propeller

Optional equipment:       Flight and engine instrument
Upholstery and carpet
 Cabin heat and ventilation system
 Nav/Strobe lights
 Wheel pants
 Radios
