FMP Qualt 201

The company was established in 1991. Mainly it produces metal valves and connecting elements for pipeline systems, moulds for compression plastics moulding, tinsmith’s roofs components, propeller blades for wind power plants and ultralight aircraft.

The company has got about 200 employees in several workshops in the Czech Republic. Engine choices are; Jabiru2200, Rotax582 2V, Rotax912UL2, Rotax912ULS2.

specifications

  Q201J Q201R
powerplant
propeller
length
height
wing span
wing area
seats
empty weight
 useful load
gross weight
fuel capacity
range		 Jabiru2200
Two bladed fixed propeller V250
 6,1 m
 1,7 m
 9,2 m
 x
 x
 265 kg
x
 450 kg
 x
 x		 Rotax912UL2
 Two bladed fixed propeller V230D
 6,1 m
 1,7 m
 9,2 m
x
x
 282 kg
x
 450 kg
x
 x

performance

takeoff distance, ground roll
rate of climb
max speed
cruise speed
landing distance, ground roll
 service ceiling		 x
 5m/sec
 230kph
 140-190kph
x
x		 x
 5m/sec
 220kph
 140-190kph
x
x

limiting and recommended speeds

design manoeuvring speed (Va)
never exceed speed (Vne)
stall, power off (Vsl)
landing approach speed 		x
x
 71kph
x		 x
x
 71kph
x

All specifications are based on manufacturer's calculations

Over-standard equipment

 in accordance to customer demands:

  • integrated airborne recovery parachute system

  • air radio equipment

  • automatic response unit in accordance to the aircraft user’s country

  • inner and outer equipment for flight in accordance to IFR

  • GPS system of navigation

  • larger petrol tanks ( more 35 litres )

 Version Qualt 201R – over standard:

  • two bladed or three bladed ground adjustable propellers or propellers adjustable manually in flight

 Version Qualt 201RS – over standard:

  • three bladed ground adjustable propellers or propellers adjustable manually in flight

 Q u a l t   2 0 1  R S  S u p e r

This aircraft will be equipped by the three bladed automatic hydraulic controlled Constant speed VZLU V 534 propeller together with the Rotax 912S3. This aircraft is suitable for very short airfields and it can be utilized for the professional purposes, too. It has been designed respecting higher weight levels in accordance to the specifications of Sport Airplane take-off weight of 560 kg.

Additional equipment:

·         Observing and reconnaissance equipment

·         Towing equipment for gliders

·         Carry container with loading capacity of 100 kg

·         Spraying device for agriculture crop with capacity of 100 litres of chemical fluid

·         Floats

·         This aircraft can be equipped by the Jabiru 3300 or Rotax 912.80 HP.
