         A join-venture of Aerospatiale and MBB
         projected at the end of the 70s and started in 1984 to provide an
         attack helicopter to the German ( PAH-2 anti tank variant ) and French
         Armies ( HAP / HAC escort variant )

         Due highly costs, the program was cancelled in 1986 but was re-launched
         during 1987 and 5 prototypes were built. In the 90s, the demise of the
         Warsaw Pact threat, forced to Eurocopter look for the international
         market.
         First flight of the
         aircraft was in 1991. Serial production began in March 2002 and the
         first flight of the production Tiger HAP for France took place in March
         2003. France has ordered 80 aircraft (70 combat support HAP and 10
         antitank HAC ) with deliveries to commence in September 2003.

         Germany has ordered 80 UHT combat support aircraft with deliveries to
         begin by the end of 2003.
         Total procurement is planned to be 120 for France and 120 for Germany.


         In December 2001, Eurocopter, with the Tiger ARH (armed
         reconnaissance), was awarded the contract for the Australian Army’s Air
         87 requirement for 22 helicopters. The Tiger ARH is a modified version
         of the Tiger HAP with upgraded MTR390 engines and a laser designator
         incorporated in the Strix sight for the firing of Hellfire II
         air-to-ground missiles. The first Tiger ARH is scheduled to enter
         service in 2004. Australian Aerospace (a subsidiary of Eurocopter) is
         to set up a local production facility for assembly of the helicopters
         and the manufacture of parts for the entire programme. ADI Ltd will be
         a major subcontractor, responsible for customising the mission and
         communications systems.

         In September 2003, Spain selected a version of the Tiger HAP combat
         support helicopter to be called the HAD which will be armed with the
         Trigat LR and Mistral missile systems. 24 helicopters will be ordered
         which will also have an uprated Enhanced MTR390 engine and a heavier
         payload. Deliveries are scheduled for 2007-08.





         First Flight :
         March 27, 1991
         Crew: 2

         Type: Attack

         Engines: 2 * 1280 shp MTU/Rolls-Royce/Turbomeca MTR390 turbine
         engines
         Speed : 260 km/h
         Rate of climb: 600 m/min
         Endurance: 2 h 50 min
         Weight: 3300 kg -- Max: 6000
          |
