         The Hughes (later
         McDonnell Douglas Helicopter Systems) OH-6 was originally designed to
         meet the needs of the US Army 's LOH competition, but it gave
         rise to a large family of commercial, corporate, and private
         helicopters. Light, nimble, and easily maintained, the MD500, as it
         became known, is designed to carry four or more passengers in a small
         but comfortable cabin. Many different versions have been built for both
         the military and civil markets for a variety of missions and
         requirements.
         Was also built with
         license in Argentina by RACA, in Japan by Kawasaki , in South Korea by
         Korean Air and in Italy by Breda - Nardi

         Latest version, equipped with a new rotorless tail that uses jet thrust
         rather than blades to give the helicopter directional stability, is
         called NOTAR (NO TAil Rotor). Without the noisy tail rotor, the NOTAR
         is one of the world's quietest helicopters.




         First flight:
         27 February 1963
         Nicknames:
         Cayuse, Loach, The Egg
         Type: Light Observation Helicopter (LOH)
         Crew: pilot, observer and 4 passengers
         Engine: one 317 hp Allison T63-A-5A
         Weight: empty: 524 kg max: 1224 kg
         Performance: max range: 611 km ferry range: 3560 km max speed:
         272 km/h
         Dimensions length: 7.04 m height: 2.59 m rotor diameter: 8.03 m
         overall length: 9.24 m
         Armament: one 7.62 mm minigun with 2000 bullets or a 40 mm
         grenade launcher with 150 rounds of ammunition.
