MiG-21 Fishbed
|
Origin: |
USSR |
|
Type: |
multi-role
fighter |
|
Max Speed: |
1,203 kt /
1,385 mph |
|
Max Range |
1,160 km / 721
miles |
|
Dimensions: |
span 7.15 m /
23 ft 5.5 in
length 15.76 m / 51 ft 8.5 in
height 4.10 m / 13 ft 5.4 in |
|
Weight: |
empty 5,200 kg
/ 11,464 lb
max. take-off 22,925 lb /
10,400 kg |
|
Powerplant: |
one 7500-kg
(16,535-lb) afterburning thrust Tumanskii R-25 turbojet |
|
Armament: |
one 23-mm
GSh-23 two-barrel cannon with 200 rounds, plus four underwing pylons
suitable for AA-2 'Atoll' orAA-8 'Aphid' AAMs, UV-16-57 rocket
launchers, 500- or 250-kg (1,102- or 551-lb) bombs, S-24
240-mm(9.45-in) air-to-surface rockets, or drop tanks |
|
|
