SAAB 35 Draken
|
Origin: |
Sweden |
|
Type: |
single-seat
interceptor |
|
Max Speed: |
1,146 kt /
1,320 mph |
|
Max Range |
560 km / 348
miles |
|
Dimensions: |
span 9.40 m /
30 ft 10.1 in
length 15.35 m / 50 ft 4.3 in
height 3.89 m / 12 ft 9.1 in |
|
Weight: |
empty 7,425 kg
/ 16,369 lb
max. take-off 16,000 kg /
35,274 lb |
|
Powerplant: |
one 7830-kg
(17,262-lb) afterburning thrust Volvo Flygmotor RM6C turbojet |
|
Armament: |
one 30-mm Aden
M/55 cannon with 90 rounds, and two radar-homing Rb27 and two IR-homing
Rb28 Falcon AAMs, or two or four Rb74 Sidewinder AAMs, or up to 4082
kg (9,000 Ib) of bombs in an attack mission |
|
|
