Cessna 335 & 340 history, performance and specifications
Development of
the Cessna 340 began in 1969, with
deliveries commencing in 1971. Whilst it
borrowed the wing design of the Cessna 414
and the undercarriage of the 310, it
introduced an all-new pressurised fuselage
which, at the time of its release, made it
the only pressurised 6-seat twin from a
major manufacturer apart from the Beechcraft
Duke.
The 340 was initially powered by 285 hp (210
kW) TSIO-520-K engines. The 340A of 1976
replaced these with the TSIO-520-NB,
offering two variants with differences in
the fitted avionics.
From 1979, the externally similar but
un-pressurised Cessna 335 became available,
at lower cost, with 300 hp (225 kW)
TSIO-520-EB engines. Only 65 of this version
were built before production ended in 1980.
The last 340 was built in 1984.
1287 340s and 64 335s were built. The 340
was in production between 1971 and 1984, the
335 between 1979 and 1981.
(Data for
Cessna 340A)
- TYPE:
Six-seat business twin.
- PERIOD
BUILT: 1971-84.
- COUNTRY
OF ORIGIN: United States
- ENGINES:
Two Continental TSI0-520-NB tubocharged
and fuel injected flat six piston engine
of 310 hp / 230 kW driving constant speed
3 bladed props.
-
DIMENSIONS:
-
Wing span:
38 ft 1 in / 11.62 m.
Length:
34 ft 4 in / 10.46 m
Height:
12 ft 7 in / 3.84 m.
WEIGHTS:
-
Empty:
3,921 lb / 1780 kg
Max.
takeoff: 5,990 lb / 2719 kg
PERFORMANCE:
-
Max. speed:
244 kt / 452 kph
Economical cruise: 170 kt / 315 kph at
25,000 ft.
Initial
climb: 1,650 ft per min.
Service
ceiling: 29,800 ft.
Range:
1,405 nm / 2603 km with reserves at
economical cruising speed.
CAPACITY:
Typical seating for six, including a
pilot.
|
|
